Mr. FN Wong visited Serbia

by | Jun 1, 2015 | Uncategorized

Mr. FN Wong from Advanced Reliability Services (ARS) in Singapore, NORTH Protection’s Master Distributor for South East Asia, visited our company in May. His visit provided us opportunity to further develop together strategies for starting cooperation between our companies and established foundations for our strategic business...
MSS-1010 Multi-Sensor Simulator

MSS-1010 Multi-Sensor Simulator

by | May 13, 2015 | Uncategorized

MSS – 1010  is a battery operated instrument that is used to electronically simulate variety of outputs from various types of accelerometers. MSS-1010 uses a menu-driven 4×16 character LCD display to establish appropriate settings. The key panel contains five sealed switches marked with arrows, E (Enter), Back and ON/OFF. Power is supplied by 4AA internally mounted rechargeable Ni-MH batteries, which can be recharged with a regulated 9Vdc source. Connection to PC is established over the front mounted LEMO connector. PC mode will be automatically started after inserting proper cable into device. Output  signal  is  user  selectable  from: single-ended  napon  (mV),  single-ended ®charge (pC), differental charge (pC), current-sinking IEPE (ICP), tachometer (TTL), ®flow (TTL), OSO  (Optical Speed Output) and BOV (Bias Output Voltage). Frequency range is 1Hz to 1kHz; output voltage RMS is from 10mV to 10V or 10pC to 10.000pC. Outputs can be provided in acceleration, velocity, displacement, voltage or charge. Application note Suitable for inspecting measurement lines according to ISO 10816 standards. Device is especially designed for Condition Monitoring  Systems  (CMS)  and/or  Vibration  Monitoring Systems (VMS) that connect to SCADA Systems.     Features Datasheet Software User Manual Specification Simulates accelerometer signals Tachometer TTL and OSO®  output BOV sensor test Menu-driven operation Multi language menu Metric and imperial units PC connection Battery operated MSS-1010 DT v02 – MSS-1010 UM v03 Outputs Type: Single-ended voltage (mV) IEPE (ICP®) – current sinking Single-ended charge (pC) Differential charge (pC) Tachometer (TTL) Flow meter (TTL) OSO®  – Optical Speed Output BOV – Bias Output Voltage Signals generator Frequency range: 1Hz – 1kHz, accuracy ±1% Amplitude:  Adjustable up to 10 000mV RMS Distortion...
HPP Me?uvršje

HPP Me?uvršje

by | May 13, 2015 | Uncategorized

Projects GroupThermal Power Plants (TPP) Hydro Power Plants (HPP) Other Industry Sectors (OIS) System NEMO 2013 is a modular multi-channel system for simultaneous online monitoring and protection aggregates fromvibration, in accordance with: ISO 10816-1:1996 and ISO 10816-5:2000 for absolute bearing vibrations Group of ISO 7919 standards for relative shaft vibration. Manufacturer of the system is American company ProVibtech and within it, is provided the monitoring absolute vibration –vibration hydro-aggregates beds, and relative vibration – vibration back into the zone of hydro-aggregates beds. The system is installed in Hydropower plant “Me?uvršje”. The number of channels from which to form a monitoring system is virtually unlimited and depends only on the projected needs. In this case set a 13 – channel system for the protection of hydro-aggregates bearings according to ISO 10816-5:2000 and platepackage in accordance with ISO 10816-1:1996 and recommendations HYDRO QUEBEC. In addition, the system allows you to connect to the SCADA system at the analog level. In accordance with the terms of reference next measurements are covered: absolute casing vibrations of upper carrier bearing in generator, from X and Y axes in the radial direction. absolute casing vibrations of carrier bearing in the axial direction. the relative vibrations of the shaft in the region of the upper guide bearing the X and Y axes in the radial direction. absolute casing vibrations of bottom carrier bearing in generator, from X and Y axes in the radial direction. the relative vibrations of the shaft in a carrier bearing of the lower zone of the X and Y axes in the radial direction. absolute casing vibrations of the turbine carrier bearing of the X...
